src/gui/guiTable.cpp

   1 /*
   2 Minetest
   3 Copyright (C) 2013 celeron55, Perttu Ahola <celeron55@gmail.com>
   4
   5 This program is free software; you can redistribute it and/or modify
   6 it under the terms of the GNU Lesser General Public License as published by
   7 the Free Software Foundation; either version 2.1 of the License, or
   8 (at your option) any later version.
   9
  10 This program is distributed in the hope that it will be useful,
  11 but WITHOUT ANY WARRANTY; without even the implied warranty of
  12 MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
  13 GNU Lesser General Public License for more details.
  14
  15 You should have received a copy of the GNU Lesser General Public License along
  16 with this program; if not, write to the Free Software Foundation, Inc.,
  17 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA.
  18 */
  19
  20
  21 #include "guiTable.h"
  22 #include <queue>
  23 #include <sstream>
  24 #include <utility>
  25 #include <cstring>
  26 #include <IGUISkin.h>
  27 #include <IGUIFont.h>
  28 #include <IGUIScrollBar.h>
  29 #include "client/renderingengine.h"
  30 #include "debug.h"
  31 #include "log.h"
  32 #include "client/tile.h"
  33 #include "gettime.h"
  34 #include "util/string.h"
  35 #include "util/numeric.h"
  36 #include "util/string.h" // for parseColorString()
  37 #include "settings.h" // for settings
  38 #include "porting.h" // for dpi
  39 #include "guiscalingfilter.h"
  40
  41 /*
  42         GUITable
  43 */
  44
  45 GUITable::GUITable(gui::IGUIEnvironment *env,
  46                 gui::IGUIElement* parent, s32 id,
  47                 core::rect<s32> rectangle,
  48                 ISimpleTextureSource *tsrc
  49 ):
  50         gui::IGUIElement(gui::EGUIET_ELEMENT, env, parent, id, rectangle),
  51         m_tsrc(tsrc)
  52 {
  53         assert(tsrc != NULL);
  54
  55         gui::IGUISkin* skin = Environment->getSkin();
  56
  57         m_font = skin->getFont();
  58         if (m_font) {
  59                 m_font->grab();
  60                 m_rowheight = m_font->getDimension(L"A").Height + 4;
  61                 m_rowheight = MYMAX(m_rowheight, 1);
  62         }
  63
  64         const s32 s = skin->getSize(gui::EGDS_SCROLLBAR_SIZE);
  65         m_scrollbar = Environment->addScrollBar(false,
  66                         core::rect<s32>(RelativeRect.getWidth() - s,
  67                                         0,
  68                                         RelativeRect.getWidth(),
  69                                         RelativeRect.getHeight()),
  70                         this, -1);
  71         m_scrollbar->setSubElement(true);
  72         m_scrollbar->setTabStop(false);
  73         m_scrollbar->setAlignment(gui::EGUIA_LOWERRIGHT, gui::EGUIA_LOWERRIGHT,
  74                         gui::EGUIA_UPPERLEFT, gui::EGUIA_LOWERRIGHT);
  75         m_scrollbar->setVisible(false);
  76         m_scrollbar->setPos(0);
  77
  78         setTabStop(true);
  79         setTabOrder(-1);
  80         updateAbsolutePosition();
  81         float density = RenderingEngine::getDisplayDensity();
  82 #ifdef __ANDROID__
  83         density = 1; // dp scaling is applied by the skin
  84 #endif
  85         core::rect<s32> relative_rect = m_scrollbar->getRelativePosition();
  86         s32 width = (relative_rect.getWidth() / (2.0 / 3.0)) * density *
  87                         g_settings->getFloat("gui_scaling");
  88         m_scrollbar->setRelativePosition(core::rect<s32>(
  89                         relative_rect.LowerRightCorner.X-width,relative_rect.UpperLeftCorner.Y,
  90                         relative_rect.LowerRightCorner.X,relative_rect.LowerRightCorner.Y
  91                         ));
  92 }
  93
  94 GUITable::~GUITable()
  95 {
  96         for (GUITable::Row &row : m_rows)
  97                 delete[] row.cells;
  98
  99         if (m_font)
 100                 m_font->drop();
 101
 102         m_scrollbar->remove();
 103 }
 104
 105 GUITable::Option GUITable::splitOption(const std::string &str)
 106 {
 107         size_t equal_pos = str.find('=');
 108         if (equal_pos == std::string::npos)
 109                 return GUITable::Option(str, "");
 110
 111         return GUITable::Option(str.substr(0, equal_pos),
 112                         str.substr(equal_pos + 1));
 113 }
 114
 115 void GUITable::setTextList(const std::vector<std::string> &content,
 116                 bool transparent)
 117 {
 118         clear();
 119
 120         if (transparent) {
 121                 m_background.setAlpha(0);
 122                 m_border = false;
 123         }
 124
 125         m_is_textlist = true;
 126
 127         s32 empty_string_index = allocString("");
 128
 129         m_rows.resize(content.size());
 130         for (s32 i = 0; i < (s32) content.size(); ++i) {
 131                 Row *row = &m_rows[i];
 132                 row->cells = new Cell[1];
 133                 row->cellcount = 1;
 134                 row->indent = 0;
 135                 row->visible_index = i;
 136                 m_visible_rows.push_back(i);
 137
 138                 Cell *cell = row->cells;
 139                 cell->xmin = 0;
 140                 cell->xmax = 0x7fff;  // something large enough
 141                 cell->xpos = 6;
 142                 cell->content_type = COLUMN_TYPE_TEXT;
 143                 cell->content_index = empty_string_index;
 144                 cell->tooltip_index = empty_string_index;
 145                 cell->color.set(255, 255, 255, 255);
 146                 cell->color_defined = false;
 147                 cell->reported_column = 1;
 148
 149                 // parse row content (color)
 150                 const std::string &s = content[i];
 151                 if (s[0] == '#' && s[1] == '#') {
 152                         // double # to escape
 153                         cell->content_index = allocString(s.substr(2));
 154                 }
 155                 else if (s[0] == '#' && s.size() >= 7 &&
 156                                 parseColorString(
 157                                         s.substr(0,7), cell->color, false)) {
 158                         // single # for color
 159                         cell->color_defined = true;
 160                         cell->content_index = allocString(s.substr(7));
 161                 }
 162                 else {
 163                         // no #, just text
 164                         cell->content_index = allocString(s);
 165                 }
 166
 167         }
 168
 169         allocationComplete();
 170
 171         // Clamp scroll bar position
 172         updateScrollBar();
 173 }
 174
 175 void GUITable::setTable(const TableOptions &options,
 176                 const TableColumns &columns,
 177                 std::vector<std::string> &content)
 178 {
 179         clear();
 180
 181         // Naming conventions:
 182         // i is always a row index, 0-based
 183         // j is always a column index, 0-based
 184         // k is another index, for example an option index
 185
 186         // Handle a stupid error case... (issue #1187)
 187         if (columns.empty()) {
 188                 TableColumn text_column;
 189                 text_column.type = "text";
 190                 TableColumns new_columns;
 191                 new_columns.push_back(text_column);
 192                 setTable(options, new_columns, content);
 193                 return;
 194         }
 195
 196         // Handle table options
 197         video::SColor default_color(255, 255, 255, 255);
 198         s32 opendepth = 0;
 199         for (const Option &option : options) {
 200                 const std::string &name = option.name;
 201                 const std::string &value = option.value;
 202                 if (name == "color")
 203                         parseColorString(value, m_color, false);
 204                 else if (name == "background")
 205                         parseColorString(value, m_background, false);
 206                 else if (name == "border")
 207                         m_border = is_yes(value);
 208                 else if (name == "highlight")
 209                         parseColorString(value, m_highlight, false);
 210                 else if (name == "highlight_text")
 211                         parseColorString(value, m_highlight_text, false);
 212                 else if (name == "opendepth")
 213                         opendepth = stoi(value);
 214                 else
 215                         errorstream<<"Invalid table option: \""<<name<<"\""
 216                                 <<" (value=\""<<value<<"\")"<<std::endl;
 217         }
 218
 219         // Get number of columns and rows
 220         // note: error case columns.size() == 0 was handled above
 221         s32 colcount = columns.size();
 222         assert(colcount >= 1);
 223         // rowcount = ceil(cellcount / colcount) but use integer arithmetic
 224         s32 rowcount = (content.size() + colcount - 1) / colcount;
 225         assert(rowcount >= 0);
 226         // Append empty strings to content if there is an incomplete row
 227         s32 cellcount = rowcount * colcount;
 228         while (content.size() < (u32) cellcount)
 229                 content.emplace_back("");
 230
 231         // Create temporary rows (for processing columns)
 232         struct TempRow {
 233                 // Current horizontal position (may different between rows due
 234                 // to indent/tree columns, or text/image columns with width<0)
 235                 s32 x;
 236                 // Tree indentation level
 237                 s32 indent;
 238                 // Next cell: Index into m_strings or m_images
 239                 s32 content_index;
 240                 // Next cell: Width in pixels
 241                 s32 content_width;
 242                 // Vector of completed cells in this row
 243                 std::vector<Cell> cells;
 244                 // Stores colors and how long they last (maximum column index)
 245                 std::vector<std::pair<video::SColor, s32> > colors;
 246
 247                 TempRow(): x(0), indent(0), content_index(0), content_width(0) {}
 248         };
 249         TempRow *rows = new TempRow[rowcount];
 250
 251         // Get em width. Pedantically speaking, the width of "M" is not
 252         // necessarily the same as the em width, but whatever, close enough.
 253         s32 em = 6;
 254         if (m_font)
 255                 em = m_font->getDimension(L"M").Width;
 256
 257         s32 default_tooltip_index = allocString("");
 258
 259         std::map<s32, s32> active_image_indices;
 260
 261         // Process content in column-major order
 262         for (s32 j = 0; j < colcount; ++j) {
 263                 // Check column type
 264                 ColumnType columntype = COLUMN_TYPE_TEXT;
 265                 if (columns[j].type == "text")
 266                         columntype = COLUMN_TYPE_TEXT;
 267                 else if (columns[j].type == "image")
 268                         columntype = COLUMN_TYPE_IMAGE;
 269                 else if (columns[j].type == "color")
 270                         columntype = COLUMN_TYPE_COLOR;
 271                 else if (columns[j].type == "indent")
 272                         columntype = COLUMN_TYPE_INDENT;
 273                 else if (columns[j].type == "tree")
 274                         columntype = COLUMN_TYPE_TREE;
 275                 else
 276                         errorstream<<"Invalid table column type: \""
 277                                 <<columns[j].type<<"\""<<std::endl;
 278
 279                 // Process column options
 280                 s32 padding = myround(0.5 * em);
 281                 s32 tooltip_index = default_tooltip_index;
 282                 s32 align = 0;
 283                 s32 width = 0;
 284                 s32 span = colcount;
 285
 286                 if (columntype == COLUMN_TYPE_INDENT) {
 287                         padding = 0; // default indent padding
 288                 }
 289                 if (columntype == COLUMN_TYPE_INDENT ||
 290                                 columntype == COLUMN_TYPE_TREE) {
 291                         width = myround(em * 1.5); // default indent width
 292                 }
 293
 294                 for (const Option &option : columns[j].options) {
 295                         const std::string &name = option.name;
 296                         const std::string &value = option.value;
 297                         if (name == "padding")
 298                                 padding = myround(stof(value) * em);
 299                         else if (name == "tooltip")
 300                                 tooltip_index = allocString(value);
 301                         else if (name == "align" && value == "left")
 302                                 align = 0;
 303                         else if (name == "align" && value == "center")
 304                                 align = 1;
 305                         else if (name == "align" && value == "right")
 306                                 align = 2;
 307                         else if (name == "align" && value == "inline")
 308                                 align = 3;
 309                         else if (name == "width")
 310                                 width = myround(stof(value) * em);
 311                         else if (name == "span" && columntype == COLUMN_TYPE_COLOR)
 312                                 span = stoi(value);
 313                         else if (columntype == COLUMN_TYPE_IMAGE &&
 314                                         !name.empty() &&
 315                                         string_allowed(name, "0123456789")) {
 316                                 s32 content_index = allocImage(value);
 317                                 active_image_indices.insert(std::make_pair(
 318                                                         stoi(name),
 319                                                         content_index));
 320                         }
 321                         else {
 322                                 errorstream<<"Invalid table column option: \""<<name<<"\""
 323                                         <<" (value=\""<<value<<"\")"<<std::endl;
 324                         }
 325                 }
 326
 327                 // If current column type can use information from "color" columns,
 328                 // find out which of those is currently active
 329                 if (columntype == COLUMN_TYPE_TEXT) {
 330                         for (s32 i = 0; i < rowcount; ++i) {
 331                                 TempRow *row = &rows[i];
 332                                 while (!row->colors.empty() && row->colors.back().second < j)
 333                                         row->colors.pop_back();
 334                         }
 335                 }
 336
 337                 // Make template for new cells
 338                 Cell newcell;
 339                 newcell.content_type = columntype;
 340                 newcell.tooltip_index = tooltip_index;
 341                 newcell.reported_column = j+1;
 342
 343                 if (columntype == COLUMN_TYPE_TEXT) {
 344                         // Find right edge of column
 345                         s32 xmax = 0;
 346                         for (s32 i = 0; i < rowcount; ++i) {
 347                                 TempRow *row = &rows[i];
 348                                 row->content_index = allocString(content[i * colcount + j]);
 349                                 const core::stringw &text = m_strings[row->content_index];
 350                                 row->content_width = m_font ?
 351                                         m_font->getDimension(text.c_str()).Width : 0;
 352                                 row->content_width = MYMAX(row->content_width, width);
 353                                 s32 row_xmax = row->x + padding + row->content_width;
 354                                 xmax = MYMAX(xmax, row_xmax);
 355                         }
 356                         // Add a new cell (of text type) to each row
 357                         for (s32 i = 0; i < rowcount; ++i) {
 358                                 newcell.xmin = rows[i].x + padding;
 359                                 alignContent(&newcell, xmax, rows[i].content_width, align);
 360                                 newcell.content_index = rows[i].content_index;
 361                                 newcell.color_defined = !rows[i].colors.empty();
 362                                 if (newcell.color_defined)
 363                                         newcell.color = rows[i].colors.back().first;
 364                                 rows[i].cells.push_back(newcell);
 365                                 rows[i].x = newcell.xmax;
 366                         }
 367                 }
 368                 else if (columntype == COLUMN_TYPE_IMAGE) {
 369                         // Find right edge of column
 370                         s32 xmax = 0;
 371                         for (s32 i = 0; i < rowcount; ++i) {
 372                                 TempRow *row = &rows[i];
 373                                 row->content_index = -1;
 374
 375                                 // Find content_index. Image indices are defined in
 376                                 // column options so check active_image_indices.
 377                                 s32 image_index = stoi(content[i * colcount + j]);
 378                                 std::map<s32, s32>::iterator image_iter =
 379                                         active_image_indices.find(image_index);
 380                                 if (image_iter != active_image_indices.end())
 381                                         row->content_index = image_iter->second;
 382
 383                                 // Get texture object (might be NULL)
 384                                 video::ITexture *image = NULL;
 385                                 if (row->content_index >= 0)
 386                                         image = m_images[row->content_index];
 387
 388                                 // Get content width and update xmax
 389                                 row->content_width = image ? image->getOriginalSize().Width : 0;
 390                                 row->content_width = MYMAX(row->content_width, width);
 391                                 s32 row_xmax = row->x + padding + row->content_width;
 392                                 xmax = MYMAX(xmax, row_xmax);
 393                         }
 394                         // Add a new cell (of image type) to each row
 395                         for (s32 i = 0; i < rowcount; ++i) {
 396                                 newcell.xmin = rows[i].x + padding;
 397                                 alignContent(&newcell, xmax, rows[i].content_width, align);
 398                                 newcell.content_index = rows[i].content_index;
 399                                 rows[i].cells.push_back(newcell);
 400                                 rows[i].x = newcell.xmax;
 401                         }
 402                         active_image_indices.clear();
 403                 }
 404                 else if (columntype == COLUMN_TYPE_COLOR) {
 405                         for (s32 i = 0; i < rowcount; ++i) {
 406                                 video::SColor cellcolor(255, 255, 255, 255);
 407                                 if (parseColorString(content[i * colcount + j], cellcolor, true))
 408                                         rows[i].colors.emplace_back(cellcolor, j+span);
 409                         }
 410                 }
 411                 else if (columntype == COLUMN_TYPE_INDENT ||
 412                                 columntype == COLUMN_TYPE_TREE) {
 413                         // For column type "tree", reserve additional space for +/-
 414                         // Also enable special processing for treeview-type tables
 415                         s32 content_width = 0;
 416                         if (columntype == COLUMN_TYPE_TREE) {
 417                                 content_width = m_font ? m_font->getDimension(L"+").Width : 0;
 418                                 m_has_tree_column = true;
 419                         }
 420                         // Add a new cell (of indent or tree type) to each row
 421                         for (s32 i = 0; i < rowcount; ++i) {
 422                                 TempRow *row = &rows[i];
 423
 424                                 s32 indentlevel = stoi(content[i * colcount + j]);
 425                                 indentlevel = MYMAX(indentlevel, 0);
 426                                 if (columntype == COLUMN_TYPE_TREE)
 427                                         row->indent = indentlevel;
 428
 429                                 newcell.xmin = row->x + padding;
 430                                 newcell.xpos = newcell.xmin + indentlevel * width;
 431                                 newcell.xmax = newcell.xpos + content_width;
 432                                 newcell.content_index = 0;
 433                                 newcell.color_defined = !rows[i].colors.empty();
 434                                 if (newcell.color_defined)
 435                                         newcell.color = rows[i].colors.back().first;
 436                                 row->cells.push_back(newcell);
 437                                 row->x = newcell.xmax;
 438                         }
 439                 }
 440         }
 441
 442         // Copy temporary rows to not so temporary rows
 443         if (rowcount >= 1) {
 444                 m_rows.resize(rowcount);
 445                 for (s32 i = 0; i < rowcount; ++i) {
 446                         Row *row = &m_rows[i];
 447                         row->cellcount = rows[i].cells.size();
 448                         row->cells = new Cell[row->cellcount];
 449                         memcpy((void*) row->cells, (void*) &rows[i].cells[0],
 450                                         row->cellcount * sizeof(Cell));
 451                         row->indent = rows[i].indent;
 452                         row->visible_index = i;
 453                         m_visible_rows.push_back(i);
 454                 }
 455         }
 456
 457         if (m_has_tree_column) {
 458                 // Treeview: convert tree to indent cells on leaf rows
 459                 for (s32 i = 0; i < rowcount; ++i) {
 460                         if (i == rowcount-1 || m_rows[i].indent >= m_rows[i+1].indent)
 461                                 for (s32 j = 0; j < m_rows[i].cellcount; ++j)
 462                                         if (m_rows[i].cells[j].content_type == COLUMN_TYPE_TREE)
 463                                                 m_rows[i].cells[j].content_type = COLUMN_TYPE_INDENT;
 464                 }
 465
 466                 // Treeview: close rows according to opendepth option
 467                 std::set<s32> opened_trees;
 468                 for (s32 i = 0; i < rowcount; ++i)
 469                         if (m_rows[i].indent < opendepth)
 470                                 opened_trees.insert(i);
 471                 setOpenedTrees(opened_trees);
 472         }
 473
 474         // Delete temporary information used only during setTable()
 475         delete[] rows;
 476         allocationComplete();
 477
 478         // Clamp scroll bar position
 479         updateScrollBar();
 480 }
 481
 482 void GUITable::clear()
 483 {
 484         // Clean up cells and rows
 485         for (GUITable::Row &row : m_rows)
 486                 delete[] row.cells;
 487         m_rows.clear();
 488         m_visible_rows.clear();
 489
 490         // Get colors from skin
 491         gui::IGUISkin *skin = Environment->getSkin();
 492         m_color          = skin->getColor(gui::EGDC_BUTTON_TEXT);
 493         m_background     = skin->getColor(gui::EGDC_3D_HIGH_LIGHT);
 494         m_highlight      = skin->getColor(gui::EGDC_HIGH_LIGHT);
 495         m_highlight_text = skin->getColor(gui::EGDC_HIGH_LIGHT_TEXT);
 496
 497         // Reset members
 498         m_is_textlist = false;
 499         m_has_tree_column = false;
 500         m_selected = -1;
 501         m_sel_column = 0;
 502         m_sel_doubleclick = false;
 503         m_keynav_time = 0;
 504         m_keynav_buffer = L"";
 505         m_border = true;
 506         m_strings.clear();
 507         m_images.clear();
 508         m_alloc_strings.clear();
 509         m_alloc_images.clear();
 510 }
 511
 512 std::string GUITable::checkEvent()
 513 {
 514         s32 sel = getSelected();
 515         assert(sel >= 0);
 516
 517         if (sel == 0) {
 518                 return "INV";
 519         }
 520
 521         std::ostringstream os(std::ios::binary);
 522         if (m_sel_doubleclick) {
 523                 os<<"DCL:";
 524                 m_sel_doubleclick = false;
 525         }
 526         else {
 527                 os<<"CHG:";
 528         }
 529         os<<sel;
 530         if (!m_is_textlist) {
 531                 os<<":"<<m_sel_column;
 532         }
 533         return os.str();
 534 }
 535
 536 s32 GUITable::getSelected() const
 537 {
 538         if (m_selected < 0)
 539                 return 0;
 540
 541         assert(m_selected >= 0 && m_selected < (s32) m_visible_rows.size());
 542         return m_visible_rows[m_selected] + 1;
 543 }
 544
 545 void GUITable::setSelected(s32 index)
 546 {
 547         s32 old_selected = m_selected;
 548
 549         m_selected = -1;
 550         m_sel_column = 0;
 551         m_sel_doubleclick = false;
 552
 553         --index; // Switch from 1-based indexing to 0-based indexing
 554
 555         s32 rowcount = m_rows.size();
 556         if (rowcount == 0 || index < 0) {
 557                 return;
 558         }
 559
 560         if (index >= rowcount) {
 561                 index = rowcount - 1;
 562         }
 563
 564         // If the selected row is not visible, open its ancestors to make it visible
 565         bool selection_invisible = m_rows[index].visible_index < 0;
 566         if (selection_invisible) {
 567                 std::set<s32> opened_trees;
 568                 getOpenedTrees(opened_trees);
 569                 s32 indent = m_rows[index].indent;
 570                 for (s32 j = index - 1; j >= 0; --j) {
 571                         if (m_rows[j].indent < indent) {
 572                                 opened_trees.insert(j);
 573                                 indent = m_rows[j].indent;
 574                         }
 575                 }
 576                 setOpenedTrees(opened_trees);
 577         }
 578
 579         if (index >= 0) {
 580                 m_selected = m_rows[index].visible_index;
 581                 assert(m_selected >= 0 && m_selected < (s32) m_visible_rows.size());
 582         }
 583
 584         if (m_selected != old_selected || selection_invisible) {
 585                 autoScroll();
 586         }
 587 }
 588
 589 GUITable::DynamicData GUITable::getDynamicData() const
 590 {
 591         DynamicData dyndata;
 592         dyndata.selected = getSelected();
 593         dyndata.scrollpos = m_scrollbar->getPos();
 594         dyndata.keynav_time = m_keynav_time;
 595         dyndata.keynav_buffer = m_keynav_buffer;
 596         if (m_has_tree_column)
 597                 getOpenedTrees(dyndata.opened_trees);
 598         return dyndata;
 599 }
 600
 601 void GUITable::setDynamicData(const DynamicData &dyndata)
 602 {
 603         if (m_has_tree_column)
 604                 setOpenedTrees(dyndata.opened_trees);
 605
 606         m_keynav_time = dyndata.keynav_time;
 607         m_keynav_buffer = dyndata.keynav_buffer;
 608
 609         setSelected(dyndata.selected);
 610         m_sel_column = 0;
 611         m_sel_doubleclick = false;
 612
 613         m_scrollbar->setPos(dyndata.scrollpos);
 614 }
 615
 616 const c8* GUITable::getTypeName() const
 617 {
 618         return "GUITable";
 619 }
 620
 621 void GUITable::updateAbsolutePosition()
 622 {
 623         IGUIElement::updateAbsolutePosition();
 624         updateScrollBar();
 625 }
 626
 627 void GUITable::draw()
 628 {
 629         if (!IsVisible)
 630                 return;
 631
 632         gui::IGUISkin *skin = Environment->getSkin();
 633
 634         // draw background
 635
 636         bool draw_background = m_background.getAlpha() > 0;
 637         if (m_border)
 638                 skin->draw3DSunkenPane(this, m_background,
 639                                 true, draw_background,
 640                                 AbsoluteRect, &AbsoluteClippingRect);
 641         else if (draw_background)
 642                 skin->draw2DRectangle(this, m_background,
 643                                 AbsoluteRect, &AbsoluteClippingRect);
 644
 645         // get clipping rect
 646
 647         core::rect<s32> client_clip(AbsoluteRect);
 648         client_clip.UpperLeftCorner.Y += 1;
 649         client_clip.UpperLeftCorner.X += 1;
 650         client_clip.LowerRightCorner.Y -= 1;
 651         client_clip.LowerRightCorner.X -= 1;
 652         if (m_scrollbar->isVisible()) {
 653                 client_clip.LowerRightCorner.X =
 654                                 m_scrollbar->getAbsolutePosition().UpperLeftCorner.X;
 655         }
 656         client_clip.clipAgainst(AbsoluteClippingRect);
 657
 658         // draw visible rows
 659
 660         s32 scrollpos = m_scrollbar->getPos();
 661         s32 row_min = scrollpos / m_rowheight;
 662         s32 row_max = (scrollpos + AbsoluteRect.getHeight() - 1)
 663                         / m_rowheight + 1;
 664         row_max = MYMIN(row_max, (s32) m_visible_rows.size());
 665
 666         core::rect<s32> row_rect(AbsoluteRect);
 667         if (m_scrollbar->isVisible())
 668                 row_rect.LowerRightCorner.X -=
 669                         skin->getSize(gui::EGDS_SCROLLBAR_SIZE);
 670         row_rect.UpperLeftCorner.Y += row_min * m_rowheight - scrollpos;
 671         row_rect.LowerRightCorner.Y = row_rect.UpperLeftCorner.Y + m_rowheight;
 672
 673         for (s32 i = row_min; i < row_max; ++i) {
 674                 Row *row = &m_rows[m_visible_rows[i]];
 675                 bool is_sel = i == m_selected;
 676                 video::SColor color = m_color;
 677
 678                 if (is_sel) {
 679                         skin->draw2DRectangle(this, m_highlight, row_rect, &client_clip);
 680                         color = m_highlight_text;
 681                 }
 682
 683                 for (s32 j = 0; j < row->cellcount; ++j)
 684                         drawCell(&row->cells[j], color, row_rect, client_clip);
 685
 686                 row_rect.UpperLeftCorner.Y += m_rowheight;
 687                 row_rect.LowerRightCorner.Y += m_rowheight;
 688         }
 689
 690         // Draw children
 691         IGUIElement::draw();
 692 }
 693
 694 void GUITable::drawCell(const Cell *cell, video::SColor color,
 695                 const core::rect<s32> &row_rect,
 696                 const core::rect<s32> &client_clip)
 697 {
 698         if ((cell->content_type == COLUMN_TYPE_TEXT)
 699                         || (cell->content_type == COLUMN_TYPE_TREE)) {
 700
 701                 core::rect<s32> text_rect = row_rect;
 702                 text_rect.UpperLeftCorner.X = row_rect.UpperLeftCorner.X
 703                                 + cell->xpos;
 704                 text_rect.LowerRightCorner.X = row_rect.UpperLeftCorner.X
 705                                 + cell->xmax;
 706
 707                 if (cell->color_defined)
 708                         color = cell->color;
 709
 710                 if (m_font) {
 711                         if (cell->content_type == COLUMN_TYPE_TEXT)
 712                                 m_font->draw(m_strings[cell->content_index],
 713                                                 text_rect, color,
 714                                                 false, true, &client_clip);
 715                         else // tree
 716                                 m_font->draw(cell->content_index ? L"+" : L"-",
 717                                                 text_rect, color,
 718                                                 false, true, &client_clip);
 719                 }
 720         }
 721         else if (cell->content_type == COLUMN_TYPE_IMAGE) {
 722
 723                 if (cell->content_index < 0)
 724                         return;
 725
 726                 video::IVideoDriver *driver = Environment->getVideoDriver();
 727                 video::ITexture *image = m_images[cell->content_index];
 728
 729                 if (image) {
 730                         core::position2d<s32> dest_pos =
 731                                         row_rect.UpperLeftCorner;
 732                         dest_pos.X += cell->xpos;
 733                         core::rect<s32> source_rect(
 734                                         core::position2d<s32>(0, 0),
 735                                         image->getOriginalSize());
 736                         s32 imgh = source_rect.LowerRightCorner.Y;
 737                         s32 rowh = row_rect.getHeight();
 738                         if (imgh < rowh)
 739                                 dest_pos.Y += (rowh - imgh) / 2;
 740                         else
 741                                 source_rect.LowerRightCorner.Y = rowh;
 742
 743                         video::SColor color(255, 255, 255, 255);
 744
 745                         driver->draw2DImage(image, dest_pos, source_rect,
 746                                         &client_clip, color, true);
 747                 }
 748         }
 749 }
 750
 751 bool GUITable::OnEvent(const SEvent &event)
 752 {
 753         if (!isEnabled())
 754                 return IGUIElement::OnEvent(event);
 755
 756         if (event.EventType == EET_KEY_INPUT_EVENT) {
 757                 if (event.KeyInput.PressedDown && (
 758                                 event.KeyInput.Key == KEY_DOWN ||
 759                                 event.KeyInput.Key == KEY_UP   ||
 760                                 event.KeyInput.Key == KEY_HOME ||
 761                                 event.KeyInput.Key == KEY_END  ||
 762                                 event.KeyInput.Key == KEY_NEXT ||
 763                                 event.KeyInput.Key == KEY_PRIOR)) {
 764                         s32 offset = 0;
 765                         switch (event.KeyInput.Key) {
 766                                 case KEY_DOWN:
 767                                         offset = 1;
 768                                         break;
 769                                 case KEY_UP:
 770                                         offset = -1;
 771                                         break;
 772                                 case KEY_HOME:
 773                                         offset = - (s32) m_visible_rows.size();
 774                                         break;
 775                                 case KEY_END:
 776                                         offset = m_visible_rows.size();
 777                                         break;
 778                                 case KEY_NEXT:
 779                                         offset = AbsoluteRect.getHeight() / m_rowheight;
 780                                         break;
 781                                 case KEY_PRIOR:
 782                                         offset = - (s32) (AbsoluteRect.getHeight() / m_rowheight);
 783                                         break;
 784                                 default:
 785                                         break;
 786                         }
 787                         s32 old_selected = m_selected;
 788                         s32 rowcount = m_visible_rows.size();
 789                         if (rowcount != 0) {
 790                                 m_selected = rangelim(m_selected + offset, 0, rowcount-1);
 791                                 autoScroll();
 792                         }
 793
 794                         if (m_selected != old_selected)
 795                                 sendTableEvent(0, false);
 796
 797                         return true;
 798                 }
 799
 800                 if (event.KeyInput.PressedDown && (
 801                                 event.KeyInput.Key == KEY_LEFT ||
 802                                 event.KeyInput.Key == KEY_RIGHT)) {
 803                         // Open/close subtree via keyboard
 804                         if (m_selected >= 0) {
 805                                 int dir = event.KeyInput.Key == KEY_LEFT ? -1 : 1;
 806                                 toggleVisibleTree(m_selected, dir, true);
 807                         }
 808                         return true;
 809                 }
 810                 else if (!event.KeyInput.PressedDown && (
 811                                 event.KeyInput.Key == KEY_RETURN ||
 812                                 event.KeyInput.Key == KEY_SPACE)) {
 813                         sendTableEvent(0, true);
 814                         return true;
 815                 }
 816                 else if (event.KeyInput.Key == KEY_ESCAPE ||
 817                                 event.KeyInput.Key == KEY_SPACE) {
 818                         // pass to parent
 819                 }
 820                 else if (event.KeyInput.PressedDown && event.KeyInput.Char) {
 821                         // change selection based on text as it is typed
 822                         u64 now = porting::getTimeMs();
 823                         if (now - m_keynav_time >= 500)
 824                                 m_keynav_buffer = L"";
 825                         m_keynav_time = now;
 826
 827                         // add to key buffer if not a key repeat
 828                         if (!(m_keynav_buffer.size() == 1 &&
 829                                         m_keynav_buffer[0] == event.KeyInput.Char)) {
 830                                 m_keynav_buffer.append(event.KeyInput.Char);
 831                         }
 832
 833                         // find the selected item, starting at the current selection
 834                         // don't change selection if the key buffer matches the current item
 835                         s32 old_selected = m_selected;
 836                         s32 start = MYMAX(m_selected, 0);
 837                         s32 rowcount = m_visible_rows.size();
 838                         for (s32 k = 1; k < rowcount; ++k) {
 839                                 s32 current = start + k;
 840                                 if (current >= rowcount)
 841                                         current -= rowcount;
 842                                 if (doesRowStartWith(getRow(current), m_keynav_buffer)) {
 843                                         m_selected = current;
 844                                         break;
 845                                 }
 846                         }
 847                         autoScroll();
 848                         if (m_selected != old_selected)
 849                                 sendTableEvent(0, false);
 850
 851                         return true;
 852                 }
 853         }
 854         if (event.EventType == EET_MOUSE_INPUT_EVENT) {
 855                 core::position2d<s32> p(event.MouseInput.X, event.MouseInput.Y);
 856
 857                 if (event.MouseInput.Event == EMIE_MOUSE_WHEEL) {
 858                         m_scrollbar->setPos(m_scrollbar->getPos() +
 859                                         (event.MouseInput.Wheel < 0 ? -3 : 3) *
 860                                         - (s32) m_rowheight / 2);
 861                         return true;
 862                 }
 863
 864                 // Find hovered row and cell
 865                 bool really_hovering = false;
 866                 s32 row_i = getRowAt(p.Y, really_hovering);
 867                 const Cell *cell = NULL;
 868                 if (really_hovering) {
 869                         s32 cell_j = getCellAt(p.X, row_i);
 870                         if (cell_j >= 0)
 871                                 cell = &(getRow(row_i)->cells[cell_j]);
 872                 }
 873
 874                 // Update tooltip
 875                 setToolTipText(cell ? m_strings[cell->tooltip_index].c_str() : L"");
 876
 877                 // Fix for #1567/#1806:
 878                 // IGUIScrollBar passes double click events to its parent,
 879                 // which we don't want. Detect this case and discard the event
 880                 if (event.MouseInput.Event != EMIE_MOUSE_MOVED &&
 881                                 m_scrollbar->isVisible() &&
 882                                 m_scrollbar->isPointInside(p))
 883                         return true;
 884
 885                 if (event.MouseInput.isLeftPressed() &&
 886                                 (isPointInside(p) ||
 887                                  event.MouseInput.Event == EMIE_MOUSE_MOVED)) {
 888                         s32 sel_column = 0;
 889                         bool sel_doubleclick = (event.MouseInput.Event
 890                                         == EMIE_LMOUSE_DOUBLE_CLICK);
 891                         bool plusminus_clicked = false;
 892
 893                         // For certain events (left click), report column
 894                         // Also open/close subtrees when the +/- is clicked
 895                         if (cell && (
 896                                         event.MouseInput.Event == EMIE_LMOUSE_PRESSED_DOWN ||
 897                                         event.MouseInput.Event == EMIE_LMOUSE_DOUBLE_CLICK ||
 898                                         event.MouseInput.Event == EMIE_LMOUSE_TRIPLE_CLICK)) {
 899                                 sel_column = cell->reported_column;
 900                                 if (cell->content_type == COLUMN_TYPE_TREE)
 901                                         plusminus_clicked = true;
 902                         }
 903
 904                         if (plusminus_clicked) {
 905                                 if (event.MouseInput.Event == EMIE_LMOUSE_PRESSED_DOWN) {
 906                                         toggleVisibleTree(row_i, 0, false);
 907                                 }
 908                         }
 909                         else {
 910                                 // Normal selection
 911                                 s32 old_selected = m_selected;
 912                                 m_selected = row_i;
 913                                 autoScroll();
 914
 915                                 if (m_selected != old_selected ||
 916                                                 sel_column >= 1 ||
 917                                                 sel_doubleclick) {
 918                                         sendTableEvent(sel_column, sel_doubleclick);
 919                                 }
 920
 921                                 // Treeview: double click opens/closes trees
 922                                 if (m_has_tree_column && sel_doubleclick) {
 923                                         toggleVisibleTree(m_selected, 0, false);
 924                                 }
 925                         }
 926                 }
 927                 return true;
 928         }
 929         if (event.EventType == EET_GUI_EVENT &&
 930                         event.GUIEvent.EventType == gui::EGET_SCROLL_BAR_CHANGED &&
 931                         event.GUIEvent.Caller == m_scrollbar) {
 932                 // Don't pass events from our scrollbar to the parent
 933                 return true;
 934         }
 935
 936         return IGUIElement::OnEvent(event);
 937 }
 938
 939 /******************************************************************************/
 940 /* GUITable helper functions                                                  */
 941 /******************************************************************************/
 942
 943 s32 GUITable::allocString(const std::string &text)
 944 {
 945         std::map<std::string, s32>::iterator it = m_alloc_strings.find(text);
 946         if (it == m_alloc_strings.end()) {
 947                 s32 id = m_strings.size();
 948                 std::wstring wtext = utf8_to_wide(text);
 949                 m_strings.emplace_back(wtext.c_str());
 950                 m_alloc_strings.insert(std::make_pair(text, id));
 951                 return id;
 952         }
 953
 954         return it->second;
 955 }
 956
 957 s32 GUITable::allocImage(const std::string &imagename)
 958 {
 959         std::map<std::string, s32>::iterator it = m_alloc_images.find(imagename);
 960         if (it == m_alloc_images.end()) {
 961                 s32 id = m_images.size();
 962                 m_images.push_back(m_tsrc->getTexture(imagename));
 963                 m_alloc_images.insert(std::make_pair(imagename, id));
 964                 return id;
 965         }
 966
 967         return it->second;
 968 }
 969
 970 void GUITable::allocationComplete()
 971 {
 972         // Called when done with creating rows and cells from table data,
 973         // i.e. when allocString and allocImage won't be called anymore
 974         m_alloc_strings.clear();
 975         m_alloc_images.clear();
 976 }
 977
 978 const GUITable::Row* GUITable::getRow(s32 i) const
 979 {
 980         if (i >= 0 && i < (s32) m_visible_rows.size())
 981                 return &m_rows[m_visible_rows[i]];
 982
 983         return NULL;
 984 }
 985
 986 bool GUITable::doesRowStartWith(const Row *row, const core::stringw &str) const
 987 {
 988         if (row == NULL)
 989                 return false;
 990
 991         for (s32 j = 0; j < row->cellcount; ++j) {
 992                 Cell *cell = &row->cells[j];
 993                 if (cell->content_type == COLUMN_TYPE_TEXT) {
 994                         const core::stringw &cellstr = m_strings[cell->content_index];
 995                         if (cellstr.size() >= str.size() &&
 996                                         str.equals_ignore_case(cellstr.subString(0, str.size())))
 997                                 return true;
 998                 }
 999         }
1000         return false;
1001 }
1002
1003 s32 GUITable::getRowAt(s32 y, bool &really_hovering) const
1004 {
1005         really_hovering = false;
1006
1007         s32 rowcount = m_visible_rows.size();
1008         if (rowcount == 0)
1009                 return -1;
1010
1011         // Use arithmetic to find row
1012         s32 rel_y = y - AbsoluteRect.UpperLeftCorner.Y - 1;
1013         s32 i = (rel_y + m_scrollbar->getPos()) / m_rowheight;
1014
1015         if (i >= 0 && i < rowcount) {
1016                 really_hovering = true;
1017                 return i;
1018         }
1019         if (i < 0)
1020                 return 0;
1021
1022         return rowcount - 1;
1023 }
1024
1025 s32 GUITable::getCellAt(s32 x, s32 row_i) const
1026 {
1027         const Row *row = getRow(row_i);
1028         if (row == NULL)
1029                 return -1;
1030
1031         // Use binary search to find cell in row
1032         s32 rel_x = x - AbsoluteRect.UpperLeftCorner.X - 1;
1033         s32 jmin = 0;
1034         s32 jmax = row->cellcount - 1;
1035         while (jmin < jmax) {
1036                 s32 pivot = jmin + (jmax - jmin) / 2;
1037                 assert(pivot >= 0 && pivot < row->cellcount);
1038                 const Cell *cell = &row->cells[pivot];
1039
1040                 if (rel_x >= cell->xmin && rel_x <= cell->xmax)
1041                         return pivot;
1042
1043                 if (rel_x < cell->xmin)
1044                         jmax = pivot - 1;
1045                 else
1046                         jmin = pivot + 1;
1047         }
1048
1049         if (jmin >= 0 && jmin < row->cellcount &&
1050                         rel_x >= row->cells[jmin].xmin &&
1051                         rel_x <= row->cells[jmin].xmax)
1052                 return jmin;
1053
1054         return -1;
1055 }
1056
1057 void GUITable::autoScroll()
1058 {
1059         if (m_selected >= 0) {
1060                 s32 pos = m_scrollbar->getPos();
1061                 s32 maxpos = m_selected * m_rowheight;
1062                 s32 minpos = maxpos - (AbsoluteRect.getHeight() - m_rowheight);
1063                 if (pos > maxpos)
1064                         m_scrollbar->setPos(maxpos);
1065                 else if (pos < minpos)
1066                         m_scrollbar->setPos(minpos);
1067         }
1068 }
1069
1070 void GUITable::updateScrollBar()
1071 {
1072         s32 totalheight = m_rowheight * m_visible_rows.size();
1073         s32 scrollmax = MYMAX(0, totalheight - AbsoluteRect.getHeight());
1074         m_scrollbar->setVisible(scrollmax > 0);
1075         m_scrollbar->setMax(scrollmax);
1076         m_scrollbar->setSmallStep(m_rowheight);
1077         m_scrollbar->setLargeStep(2 * m_rowheight);
1078 }
1079
1080 void GUITable::sendTableEvent(s32 column, bool doubleclick)
1081 {
1082         m_sel_column = column;
1083         m_sel_doubleclick = doubleclick;
1084         if (Parent) {
1085                 SEvent e;
1086                 memset(&e, 0, sizeof e);
1087                 e.EventType = EET_GUI_EVENT;
1088                 e.GUIEvent.Caller = this;
1089                 e.GUIEvent.Element = 0;
1090                 e.GUIEvent.EventType = gui::EGET_TABLE_CHANGED;
1091                 Parent->OnEvent(e);
1092         }
1093 }
1094
1095 void GUITable::getOpenedTrees(std::set<s32> &opened_trees) const
1096 {
1097         opened_trees.clear();
1098         s32 rowcount = m_rows.size();
1099         for (s32 i = 0; i < rowcount - 1; ++i) {
1100                 if (m_rows[i].indent < m_rows[i+1].indent &&
1101                                 m_rows[i+1].visible_index != -2)
1102                         opened_trees.insert(i);
1103         }
1104 }
1105
1106 void GUITable::setOpenedTrees(const std::set<s32> &opened_trees)
1107 {
1108         s32 old_selected = -1;
1109         if (m_selected >= 0)
1110                 old_selected = m_visible_rows[m_selected];
1111
1112         std::vector<s32> parents;
1113         std::vector<s32> closed_parents;
1114
1115         m_visible_rows.clear();
1116
1117         for (size_t i = 0; i < m_rows.size(); ++i) {
1118                 Row *row = &m_rows[i];
1119
1120                 // Update list of ancestors
1121                 while (!parents.empty() && m_rows[parents.back()].indent >= row->indent)
1122                         parents.pop_back();
1123                 while (!closed_parents.empty() &&
1124                                 m_rows[closed_parents.back()].indent >= row->indent)
1125                         closed_parents.pop_back();
1126
1127                 assert(closed_parents.size() <= parents.size());
1128
1129                 if (closed_parents.empty()) {
1130                         // Visible row
1131                         row->visible_index = m_visible_rows.size();
1132                         m_visible_rows.push_back(i);
1133                 }
1134                 else if (parents.back() == closed_parents.back()) {
1135                         // Invisible row, direct parent is closed
1136                         row->visible_index = -2;
1137                 }
1138                 else {
1139                         // Invisible row, direct parent is open, some ancestor is closed
1140                         row->visible_index = -1;
1141                 }
1142
1143                 // If not a leaf, add to parents list
1144                 if (i < m_rows.size()-1 && row->indent < m_rows[i+1].indent) {
1145                         parents.push_back(i);
1146
1147                         s32 content_index = 0; // "-", open
1148                         if (opened_trees.count(i) == 0) {
1149                                 closed_parents.push_back(i);
1150                                 content_index = 1; // "+", closed
1151                         }
1152
1153                         // Update all cells of type "tree"
1154                         for (s32 j = 0; j < row->cellcount; ++j)
1155                                 if (row->cells[j].content_type == COLUMN_TYPE_TREE)
1156                                         row->cells[j].content_index = content_index;
1157                 }
1158         }
1159
1160         updateScrollBar();
1161
1162         // m_selected must be updated since it is a visible row index
1163         if (old_selected >= 0)
1164                 m_selected = m_rows[old_selected].visible_index;
1165 }
1166
1167 void GUITable::openTree(s32 to_open)
1168 {
1169         std::set<s32> opened_trees;
1170         getOpenedTrees(opened_trees);
1171         opened_trees.insert(to_open);
1172         setOpenedTrees(opened_trees);
1173 }
1174
1175 void GUITable::closeTree(s32 to_close)
1176 {
1177         std::set<s32> opened_trees;
1178         getOpenedTrees(opened_trees);
1179         opened_trees.erase(to_close);
1180         setOpenedTrees(opened_trees);
1181 }
1182
1183 // The following function takes a visible row index (hidden rows skipped)
1184 // dir: -1 = left (close), 0 = auto (toggle), 1 = right (open)
1185 void GUITable::toggleVisibleTree(s32 row_i, int dir, bool move_selection)
1186 {
1187         // Check if the chosen tree is currently open
1188         const Row *row = getRow(row_i);
1189         if (row == NULL)
1190                 return;
1191
1192         bool was_open = false;
1193         for (s32 j = 0; j < row->cellcount; ++j) {
1194                 if (row->cells[j].content_type == COLUMN_TYPE_TREE) {
1195                         was_open = row->cells[j].content_index == 0;
1196                         break;
1197                 }
1198         }
1199
1200         // Check if the chosen tree should be opened
1201         bool do_open = !was_open;
1202         if (dir < 0)
1203                 do_open = false;
1204         else if (dir > 0)
1205                 do_open = true;
1206
1207         // Close or open the tree; the heavy lifting is done by setOpenedTrees
1208         if (was_open && !do_open)
1209                 closeTree(m_visible_rows[row_i]);
1210         else if (!was_open && do_open)
1211                 openTree(m_visible_rows[row_i]);
1212
1213         // Change selected row if requested by caller,
1214         // this is useful for keyboard navigation
1215         if (move_selection) {
1216                 s32 sel = row_i;
1217                 if (was_open && do_open) {
1218                         // Move selection to first child
1219                         const Row *maybe_child = getRow(sel + 1);
1220                         if (maybe_child && maybe_child->indent > row->indent)
1221                                 sel++;
1222                 }
1223                 else if (!was_open && !do_open) {
1224                         // Move selection to parent
1225                         assert(getRow(sel) != NULL);
1226                         while (sel > 0 && getRow(sel - 1)->indent >= row->indent)
1227                                 sel--;
1228                         sel--;
1229                         if (sel < 0)  // was root already selected?
1230                                 sel = row_i;
1231                 }
1232                 if (sel != m_selected) {
1233                         m_selected = sel;
1234                         autoScroll();
1235                         sendTableEvent(0, false);
1236                 }
1237         }
1238 }
1239
1240 void GUITable::alignContent(Cell *cell, s32 xmax, s32 content_width, s32 align)
1241 {
1242         // requires that cell.xmin, cell.xmax are properly set
1243         // align = 0: left aligned, 1: centered, 2: right aligned, 3: inline
1244         if (align == 0) {
1245                 cell->xpos = cell->xmin;
1246                 cell->xmax = xmax;
1247         }
1248         else if (align == 1) {
1249                 cell->xpos = (cell->xmin + xmax - content_width) / 2;
1250                 cell->xmax = xmax;
1251         }
1252         else if (align == 2) {
1253                 cell->xpos = xmax - content_width;
1254                 cell->xmax = xmax;
1255         }
1256         else {
1257                 // inline alignment: the cells of the column don't have an aligned
1258                 // right border, the right border of each cell depends on the content
1259                 cell->xpos = cell->xmin;
1260                 cell->xmax = cell->xmin + content_width;
1261         }
1262 }
